Features

• Capacity: 6kVA, 10kVA

• Online Double Conversion technology

• DSP processor with three-level technology

• High Frequency PWM structure

• Wide input voltage range (110–288)

• Advanced PFC technology (Power Factor Correction)

• True sine wave output with THD less than 1% at linear load

• Automatic fault detection at startup

• Advanced Battery Management (ABM)

• Automatic battery charging while inverter is off

• Cold start function (battery startup without utility power)

• EMI/RFI filters on input and output

• LCD display showing load and battery capacity, with audible alarm

• UPS network monitoring and control capability

• Ports: RS232 (optional), SNMP (optional), USB (optional)

• Output power factor: 1

• ECO Mode for energy saving

• Optional EPO port for emergency power-off

• Dual-speed fan with temperature control

Advantages

• High-quality power output

• High-capacity charger for larger batteries and extended backup time

• Multiple communication interfaces

• Excellent adaptability to sudden load changes

• Advanced protection against electrical hazards (short circuit, overcharge, prolonged battery discharge, overheating, etc.)

Suitable For

• Medical centers, nursing stations

• Offices, commercial centers, shops

• Security systems

• Traffic control equipment

• Automation units

• Banks

• Telecommunications
